CONCRETE PUMP TRUCK

Details

 Small concrete pump truck is high reliability,economy,safety and durability with electronic control,hydraulic pump system,

reasonable configuration, convenient elescopic boom and automatic vehicle moving, high and low voltages witch,high outlet

pressure,which can meet high standards of concrete long distance transport, so it is a ideal construction equipment for  high-speed rail,beam field,bridge,airport,port,indoor construction and construction of urbanization.






SPECIFICATIONS FOR TRUCK-MOUNTED PLACING BOOM

JD5091THB18-3R
JD5091THB21-3R
JD5091THB24-4R
JD5091THB28-4R
Vertical reach  (m)
18
21
24
28
Horizontal reach (m)
15
18
21
25
reach depth (m)
11
13.5
15
17
Max. output (M3/h)
50-80
feeding height (m)
1430
Pipeline diameter(mm)
125
Hydrolice pressure(Mpa)
25
Rotation (°)
365
Model of control
radio/cable/control panel
Total weight (kg)
13000
13200
13400
13500
overall dimensions(mm)
9600*2300*3230
9600*2300*3230
9800*2300*3230
9800*2300*3230

Main Features



1,Matched with a truck concrete pump,it can achieve continuous and quickly placement
2,Low investment, low cost, easy maintance and good economy
